SYSTEM INFORMATION
Processor Specs Atheros MIPS 24KC, 400MHz
Memory Information 64MB SDRAM, 8MB Flash
Networking Interface 1 X 10/100 BASE-TX (Cat. 5, RJ-45) Ethernet Interface
REGULATORY / COMPLIANCE INFORMATION
Wireless Approvals FCC Part 90Y
RoHS Compliance YES
OPERATING FREQUENCY 3400MHz-3700MHz
TX POWER SPECIFICATIONS RX SPECIFICATIONS
DataRate Avg. TX Tolerance DataRate Sensitivity Tolerance
MCS0 25 dBm +/-2dB MCS0 -94 dBm +/-2dB
MCS1 25 dBm +/-2dB MCS1 -93 dBm +/-2dB
MCS2 25 dBm +/-2dB MCS2 -90 dBm +/-2dB
MCS3 25 dBm +/-2dB MCS3 -89 dBm +/-2dB
MCS4 24 dBm +/-2dB MCS4 -86 dBm +/-2dB
MCS5 23 dBm +/-2dB MCS5 -83 dBm +/-2dB
MCS6 22 dBm +/-2dB MCS6 -77 dBm +/-2dB
MCS7 20 dBm +/-2dB MCS7 -74 dBm +/-2dB
MCS8 25 dBm +/-2dB MCS8 -93 dBm +/-2dB
MCS9 25 dBm +/-2dB MCS9 -91 dBm +/-2dB
MCS10 25 dBm +/-2dB MCS10 -89 dBm +/-2dB
MCS11 25 dBm +/-2dB MCS11 -87 dBm +/-2dB
MCS12 24 dBm +/-2dB MCS12 -84 dBm +/-2dB
MCS13 23 dBm +/-2dB MCS13 -79 dBm +/-2dB
MCS14 22 dBm +/-2dB MCS14 -78 dBm +/-2dB
MCS15 20 dBm +/-2dB MCS15 -75 dBm +/-2dB PHYSICAL / ELECTRICAL / ENVIRONMENTAL
Enclosure Size 445 x 416 x 34mm
Weight 3.82kg
Enclosure Characteristics Outdoor UV Stabilized Plastic
Mounting Kit Pole Mounting Kit included
Max Power Consumption 8 Watts
Power Supply 24V, 1A surge portection integrated
POE adapter included
Power Method Passive Power over Ethernet (pairs 4,5+; 7,8 return)
Operating Temperature -30C to +80C
Operating Humidity 5 to 95% Condensing
Shock and Vibration ETSI300-019-1.4
INTEGRATED DUAL POLARITY ANTENNA
Frequency Range 3.3-3.8 GHz
Max VSWR 1.5:1
Gain 20 dBi
H-pol Beamwidth 13.5 deg.
V-pol Beamwidth 13.5 deg.
Polarization Dual Linear
Cross-pol Isolation dB minimum 28dB minimum
Elevation Beamwidth 13.5 deg.
